10.1 Stealth 2
Length (L)
140.5 mm 5.53"
Height (H) 106.9 mm 4.21"
Width (W) 31.8 mm 1.25"
Hex link, min 19 mm 3/4"
Hex link, max 35 mm 1 3/8"
Radius (R), min 26.1 mm 1.03"
Radius (R), max 44.6 mm 1.76"
Minimum torque 377 Nm 278 ft.lbs.
Maximum torque 2,534 Nm 1,869 ft.lbs.
Weight 2.3 kg 5.1 lbs.
10.2 Stealth 4
Length (L)
167.1 mm 6.56"
Height (H) 138.0 mm 5.43"
Width (W) 42.2 mm 1.66"
Hex link, min 35 mm 1-3/8"
Hex link, max 44 mm 1-3/4"
Radius (R), min 33.6 mm 1.32"
Radius (R), max 58.9 mm 2.32"
Minimum torque 819 Nm 604 ft.lbs.
Maximum torque 5,450 Nm 4,020 ft.lbs.
Weight 4.9 kg 10.8 lbs.
Technical data
38 37 - 001 -
