Hyundai Elevator SSVF7 - Page 14

Hyundai Elevator Co., Ltd. STVF7 SYSTEM
REV.0 2009.11.06
TITLE
File Name :
STVF7 ADJUST MANUAL
STVF7 SERIES
ADJUSTMENT MANUAL
Document Number :
Rev. Commemts :
HELCO-C5-003-01 - 13 - A4(210㎜×297㎜)
(4) Connect the connector and JP as shown in the following table. (Refer to Figure 9.)
- In case of HPI/HIP Can board at lowest floor, CH4 connector should be used
with end-resistor (120 ohm).
Name Item Name Item
SW1 Set a floor CH3
Connect CG1 on GH3 Bd
for lantern & Chime
CH1
Communication cable
from upper HPI/HIP
CH4
1)Communication cable to lower
HPI/HIP.
2)At lowest floor, connector
should be used with end-resistor.
CH2
Hall button cable SW2 Use for handicap car
CH2B
Connect hall button cable
to next HPI/HIP for group
JP1
Use for indicator scroll
on HIP CAN Board.
[Table 7. HPI/HIP Board Connection]
(5) In case that hall button for the handicap car exists ;
- For group, handicap hall button should be installed independently from other car.
(CH2B is not used)
- Handicap function for group is only used for ring group system.
- Set MCU HHT : 3.SETUP >> 3.1 Basic >> 31b Field >> B44 Handicap Use → "Enable".
- Set MCU HHT : 3.SETUP >> 3.2 Device >> 32h Hall.1 Type → "Handicap Call"
- Refer to "STVF7 HHT MANUAL" and "STVF7 GROUP CONTROL SYSTEM MANUAL".
(6) Ground Line Connection : the ground line is connected to HPI/HIP board case.
