Hyundai Elevator SSVF7 - Inspection Operation; Brake Line Connection; Power Line Connection; Motor Line Connection

Hyundai Elevator Co., Ltd. STVF7 SYSTEM
REV.0 2009.11.06
TITLE
File Name :
STVF7 ADJUST MANUAL
STVF7 SERIES
ADJUSTMENT MANUAL
Document Number :
Rev. Commemts :
HELCO-C5-003-01 - 18 - A4(210㎜×297㎜)
4. INSPECTION OPERATION
4-1. Brake line connection
- Check the connection between brake and CP terminal "TD".
- B3(TD-11), B4(TD-12), BKOP(TD-7), P24(TD-8)
4-2. Power line connection
- Check the power line connection from the building power distribution box. (R,S,T)
4-3. Motor line connection
- Check the motor line connection from inverter. (U,V,W)
4-4. Check points after turning on the power
(1) Check the setting condition of "Auto/Inspection" switches as follows
- "SW1" of TNP board -> "INS" position
- "SW3" of TNP board -> "E-STOP" position
- Car Top/Internal "AUTO/INS" switch ->"AUTO" position
(1) Check any trouble by turning on each breaker "NFB1" and "NFB2" in regular order.
(2) Check the voltage of each power supply.
Check Point Voltage
MCU Board (CM1) DC 5V
Safety Line (P110, N24) DC 110V
Input / output (P24, N24) DC 24V
Receptacle (22X, 22Y) AC 220V
[Table 7. Check Point of Voltages]
(3) Check "MCX1", "X29", "X40", "X41" relays of TNP board.
- These relays must be turned "ON" in normal.
M c C D2(B1)/33
F13 [09 : 25]
: "McCD" must be displayed in total information mode of HHT.
- If not, check the jumper cable and any other connection of TNP board.
- And refer to "STVF7 Troubleshooting manual"
