Ini t Trvl.Len? " Initialization Start" mode
▶Yes Select “Yes"
F i C D ↑ ≡ 1 ( B 2 ) / 2 8 Status of initialization
--- [09 : 25]
McCD •≡ 28 ( 26 ) / 28 The end of initialization
--- [09 : 32]
5-3. Operating Procedure
EX) Total Floor : 28Floors, Floor Marking : B2, B1, 1~26
1) Align the car at the bottom floor by inspection operation as shown in figure 16.
2) Turn AUTO/INS switch(SW1) of TNP Board to "INS" position.
3) Turn AUTO/INS switch of car junction box and OPB in car to "AUTO" position
4) Ready to start initialization with HHT.
5) 4. MANAGEMENT >> 4.3 Field Test >> 43a Field Setup
6) Change the data "2" for initialization and auto operation.
* Refer to "Table 8. Field Setup data"
7) 3. SETUP >> 3.1 Basic >> 31a General >> A19 Init TrvlLen
8) Push "ENTER" key → Select "YES" with "UP" key → Push "ENTER" key
9) Car starts operation automatically.
10) Car is stopped automatically at top floor, operation for initialization is completed.
5-4. Cautious Subjects
1) After the initialization operation is finished, check the inverter data with HHT.
"Monitor >> Basic >> Init OK " is "1".
2) If any problem occurs while the car is running or stopped, take the proper measure by
turning off the safety switch.
3) If the initializing operation failed twice, check the connectors and wiring of the encoder.
4) And if "F22, F42, F62" error occurs, check the inverter floor data and MCU floor data.
- Inverter : "PROGRAM >> CONTROL >> MAX FLOOR"
- MCU : "3.SETUP >> 3.1 Basic >> 31b Field >> B01 Total FL Num"
