6. Load Compensating Device Setup
6-1. Purpose
- To decrease start shock, MCU and inverter system must be known the cage weight.
6-2. Procedure
(1) STVF7 (Geared system)
① Fix the 30%, 70% switch under the cage.
② And connect from switch to the "CC26" of OPB-340 board.
③ Refer to electrical wiring diagram COL8B.
(2) LXVF7 (Gearless system), SSVF7 (Machine-room-less)
① Fix the LS board and LS sensor under the cage.
② LS board converts the input voltage into the pulse and supplies it to MCU
with CAN communication.
③ Connect connectors CN1,CN2 with LS sensors and turn the DIP SW1,2 on.
④ Open the door completely in landing zone and make the inspection switch be on in the
machine room. (not in the car and not on the car)
⑤ Connect HHT to MCU board.
(3) LS board setup method with HHT (LXVF7, SSVF7)
① "3.SETUP >> 3.1 Basic >> 31a General >> A20 Load Sensor >> 20a LS use"
→ set "Enable"
② Reset MCU board. (If "Enable", you don't have to do it).
③ "3.SETUP >> 3.1 Basic >> 31a General >> A20 Load Sensor >> 20c Sensing Data"
→ check "LS data : A/D" within 9000~10000.
④ If not, adjust the LS sensor position under the cage. Refer to figure 15.
⑤ "3.SETUP >> 3.1 Basic >> 31a General >> A20 Load Sensor >> 20b Load Setting"
: If HHT display "Settable", condition is good to load set.
: If "Can't Settable" displayed, check (2)-④.
(door full open, door zone, inspection switch in the machine room)
⑥ When there is no load in the cage, push ENTER key and input "YES"
in "Load Set : 0%“ HHT mode. Then buzzer rings once.
⑦ Load the weight equivalent to 50% of the rated lad on the cage.
⑧ push ENTER key and input "YES" in "Load Set : 50%“ HHT mode.
Then buzzer rings twice.
⑨ After completing the LS setting, "20c Sensing Data >> LS data: %" must display 50%.
