Hyundai Elevator SSVF7 - Introduction; Main Feature

Hyundai Elevator Co., Ltd. STVF7 SYSTEM
REV.0 2009.11.06
TITLE
File Name :
STVF7 ADJUST MANUAL
STVF7 SERIES
ADJUSTMENT MANUAL
Document Number :
Rev. Commemts :
HELCO-C5-003-01 - 3 - A4(210㎜×297㎜)
1. INTRODUCTION
1-1. Main feature
(1) STVF7, LXVF7, SSVF7 are designed to apply CAN(Controller Area Network) communication,
multi pattern drive and direct landing drive.
(2) User can check data and elevator status with HHT(Hand Held Terminal).
(3) Name
- STVF7 : Geared System
- LXVF7 : Gearless System
- SSVF7 : Machine-Room-Less System
(4) Feature
- CPU : 32 Bit Microprocessor
- Speed : ~150 meter per minute(LXVF7 : Max 150m/m)
- Floor : ~64 floor
- Group Car : ~8 car
- STVF7, LXVF7 and SSVF7 are designed to use same PCB boards.
STVF7 LXVF7 SSVF7
Main Controller PCB MCU Board
In/Out PCB PIO Board
Terminal & Power PCB TNP Board
Car Top PCB CCB-7 Board
In Car Controller PCB OPB-340 Board
In Hall Controller PCB Hall-CAN Board
Group Controller PCB
- RING GROUP (GROUP Controller + GIO)
- DUPLEX GROUP (GIO : CAN type)
Door inverter HIDC type
[Table 1. Similarity between STVF7, LXVF7, SSVF7]
- Difference between STVF7, LXVF7, SSVF7
STVF7 LXVF7 SSVF7
Motor Series TM GT, GX
GN, GF, GL,
GM, GS
Inverter 900G
900GT,
910GT,
2000GT
900SS,
2000SS
Limit position *It is different as speed and inverter.
Cable connection *Refer to electrical diagram
[Table 2. Difference between STVF7, LXVF7, SSVF7]
