4-5. Operate inspection
(1) In main controller
a. Check the data "1" in "4.MANAGEMENT >> 4.3 FieldTest >> 43a FieldSetup"
of MCU HHT menu.
b. Using UP/DOWN switch(SW2) of TNP board, operate the elevator up/down direction.
c. At that time, brake must be open in normal.
d. B3~B4 voltage : (open) DC120V~200V, (holding) DC70V~120V
(please refer to electrical diagram COL2A,2B,2C)
(2) In inverter(LXVF7, SSVF7)
a. Connect the HHT(Hand-Held-Terminal) to inverter.
b. Setup the data "0" in "PROGRAM >> MOTOR >> KNOW ANGLE" HHT menu.
c. Operate the elevator up direction for about 5 seconds.
d. Setup the data "1" in "PROGRAM >> MOTOR >> KNOW ANGLE" HHT menu.
e. Check the angle data in "PROGRAM >> MOTOR >> U ANGLE" HHT menu.
f. Do (b)~(e) one more time, and check U angle data.
g. When the U angle data is correct, you can operate up and down direction normally.
