Hyundai Elevator SSVF7 - Page 29

Hyundai Elevator Co., Ltd. STVF7 SYSTEM
REV.0 2009.11.06
TITLE
File Name :
STVF7 Trouble manual
STVF7 SERIES
TROUBLESHOOTING MANUAL
Document Number :
Rev. Commemts :
HELCO-C5-003-01 - 3 - A4(210㎜×297㎜)
1. INTRODUCTION
* The manual describes the troubleshooting method of Hyundai "STVF7, LXVF7, SSVF7"
elevator system.
* In this manual, elevator troubles are explained in two cases i.e.
* "Condition of operation impossible" means the impossible state of starting and running of
elevator by certain causes of troubles.
* "Condition of operation possible" means the possible state of running, but normal service for
passenger's is not made by several causes of troubles.
* As troubles are describes by trouble modes and causes of troubles and troubleshooting
methods are explained.
* This manual shall be helpful for prompt and accurate troubleshooting of the troubles that
could happen at jobsite.
* System power and Boards are explained in "STVF7 INSTALLATION MANUAL AND ADJUSTMENT
MANUAL"
* HHT use methods are explained in "STVF7 HHT MANUAL".
