Hyundai Elevator Co., Ltd. STVF7 SYSTEM
REV.0 2009.11.06
TITLE
File Name :
STVF7 Trouble manual
STVF7 SERIES
TROUBLESHOOTING MANUAL
Document Number :
Rev. Commemts :
HELCO-C5-003-01 - 10 - A4(210×297)
3) Hall Error (2.ERROR >> 2.3 Hall Error)
- Undetected or dis-order hall board ID bit is displayed "1".
- Check the hall board. Refer to "STVF7 ADJUSTMENT MANUAL".
HHT Commit
HallErr.1 1-32 Normal/Front Hall error 1~32 floor
HallErr.1 33-64 Normal/Front Hall error 33~64 floor
HallErr.2 1-32 Handicap/Rear Hall error 1~32 floor
HallErr.2 33-64 Handicap/Rear Hall error 33~64 floor
ex) Hall ID error is detected at 1, 2, 6, 8 floor
Ha l l E r r . 1 1-32
Hall Err.1 1-32 mode
DATA : 32bit hex value
0X000000A3
25~3217~24 9~16 1~8
0X000000A3 " ---- 8 7 6 5 4 3 2 1 floor
DATA "A3 " ---- 1 0 1 0 0 0 1 1
* If there is no hall error, DATA is displayed 0x00000000”.
