N700 Operating Instructions and Parts Manual 7. Explanation of A-Group
61
Code Function name Initial value Unit Setting range Contents
A051 5th Acceleration time 30.0 Sec. 0.1~3600 0.1~999.9/1000~3600
A052 5th deceleration time 30.0 Sec. 0.1~3600 0.1~999.9/1000~3600
A053 6th Acceleration time 30.0 Sec. 0.1~3600 0.1~999.9/1000~3600
A054 6th deceleration time 30.0 Sec. 0.1~3600 0.1~999.9/1000~3600
A055 7th Acceleration time 30.0 Sec. 0.1~3600 0.1~999.9/1000~3600
A056 7th deceleration time 30.0 Sec. 0.1~3600 0.1~999.9/1000~3600
Table 7- 7 1st~7th aceel/decel time setting (A043~A056)
7.8 Free V/f setting (A059~A072)
(1) The free V/f setting represents the optional V/f characteristics by setting the voltage and
frequency in seven parts.(A059-A072)
(2) This function provides a way to define a multi-segment V/f curve that best suits your
application.
(3) The setting of free V/f setting always operates to be 1≤2≤3≤4≤5≤6≤7.
Please set first free V/f setting 7 because the initial value is all 0Hz.
(4) When the free V/f setting is valid, the function of torque boost (C003), base frequency (F002),
maximum frequency(F003) is invalid. (Free V/f frequency 7 is same as the maximum
frequency.)
Code Function name Initial value Unit Setting range Contents
A059 Free V/F frequency 1 0.00 Hz 0.00~400.0
0.00~99.99/100.0~400.0
F1 frequency setting
A060 Free V/F voltage 1 0.0 V 0.0~999.9 Voltage of V1 setting
A061 Free V/F frequency 2 0.00 Hz 0.00~400.0
0.00~99.99/100.0~400.0
F2 frequency setting
A062 Free V/F voltage 2 0.0 V 0.0~999.9 Voltage of V2 setting
A063 Free V/F frequency 3 0.00 Hz 0.00~400.0
0.00~99.99/100.0~400.0
F3 frequency setting
A064 Free V/F voltage 3 0.0 V 0.0~999.9 Voltage of V3 setting
A065 Free V/F frequency 4 0.00 Hz 0.00~400.0
0.00~99.99/100.0~400.0
F4 frequency setting
A066 Free V/F voltage 4 0.0 V 0.0~999.9 Voltage of V4 setting
A067 Free V/F frequency 5 0.00 Hz 0.00~400.0
0.00~99.99/100.0~400.0
F5 frequency setting
A068 Free V/F voltage 5 0.0 V 0.0~999.9 Voltage of V5 setting
A069 Free V/F frequency 6 0.00 Hz 0.00~400.0
0.00~99.99/100.0~400.0
F6 frequency setting
A070 Free V/F voltage 6 0.0 V 0.0~999.9 Voltage of V6 setting
A071 Free V/F frequency 7 0.00 Hz 0.00~400.0
0.00~99.99/100.0~400.0
F7 frequency setting
A072 Free V/F voltage 7 0.0 V 0.0~999.9 Voltage of V7 setting
Table 7- 8 Free V/f setting (A059~A072)
