I-jet Trace

TARGET CONNECTIONS

These target interfaces are supported:

● MIPI-20, for up to 4-bit wide trace (part number SHF-110-01-L-D): JTAG, SWD,

cJTAG, SWO, ETM

● MIPI-10 for debugging without trace (part number SHF-105-01-L-D): JTAG, SWD,

cJTAG, SWO

● Arm-20 for debugging without trace (part number HTST-110-01-L-DV): JTAG,

SWD, cJTAG, SWO

● Mictor-38 for up to 16-bit wide trace (I-jet Trace A/R/M only): JTAG, SWD,

cJTAG, ETM, and SWO

● MIPI-60 (with trace) and TI-14/cTI-20 (without trace) connections via optional

adapters

I-jet Trace CM comes with a MIPI-20 connector on the front panel, and with MIPI-20

and MIPI-10 cables, as well as a legacy Arm-20 adapter.

I-jet Trace A/R/M comes with an adapter board with a Mictor-38 connector that plugs

directly into the target board. For boards that do not use the high-speed Mictor

connector, the pod also supports the standard MIPI-20 headers.

Note: Only the MIPI-20 and Mictor-38 cables support ETM trace functionality. All

other connections (MIPI-10 and Arm-20) are only for plain JTAG/SWD/SWO/cJTAG

debugging.

All I-jet adapters are compatible with I-jet Trace.

Working with I-jet Trace

These tasks are covered:

● Setup and installation

● Connecting the target system

● Using Trace

● Updating the probe firmware

For information about debugging using I-jet Trace, see the C-SPY® Debugging Guide

for Arm.
