Technical specifications
IAR Debug Probes User Guide
I-jet®, I-jet Trace, and I-scope™
The TPWR indicator (Target power)
The DBG indicator (JTAG/SWD/cJTAG)
The USB indicator
ADAPTERS
The following adapters are described in detail:
● The ADA-MIPI20-MICTOR adapter
● The ADA-MICTOR-MIPI60 adapter
The ADA-MIPI20-MICTOR adapter
The ADA-MIPI20-MICTOR adapter coverts the I-jet Trace CM standard MIPI-20 cable
pinout to the high-speed Mictor 38-pin trace connector used on some target boards.
Indicator status Description
Off Power to target is not provided by I-jet.
Green Power to target is provided by I-jet.
Yellow Warning. Power to target is close to the overcurrent limit.
Red Error. Overcurrent limit detected and power to target was switched off
for protection.
Table 17: TPWR indicator statuses
Indicator status Description
Off vTRef on JTAG header is too low.
Green vTRef is at or above 1.2 V.
Green blinking Indicates JTAG/cJTAG/SWD communication activity from the target
Table 18: DBG indicator statuses
Indicator status Description
Off No USB power.
Green steady Initial state or no transfer.
Green blinking USB transfers to or from I-jet Trace.
Red blinking USB enumeration.
Red steady USB did not enumerate or the hardware is broken.
Table 19: USB indicator statuses
