The ADA-MICTOR-MIPI60 adapter
The ADA-MICTOR-MIPI60 adapter converts the I-jet Trace A/R/M standard Mictor-38
pinout to the MIPI-60 trace connector used on some target boards.The adapter has the
Mictor-38 female connector on top for connecting the I-jet Trace A/R/M and the
MIPI-60-style male header on the bottom.
This MIPI-60 connector (Samtec QTH-030-01-F-D-A) mates with target boards with a
female MIPI-60 connector with the pitch size 0.5 mm (0.19 in). You can, for example,
use Samtec QSH-030-01-F-D-A. These connectors are keyed to prevent incorrect
insertion.
GND 5 6 TRACECLK
78
nSRST 9 10
TDO 11 12 VTREF
RTCK
*
13 14 VSUPPLY
TCK 15 16
TMS 17 18
TDI 19 20
nTSRST
*
21 22
23 24 TD[3]
25 26 TD[2]
27 28 TD[1]
29 30
31 32
33 34
35 36
37 38 TD[0]
Signal Pin Pin Signal
Table 20: ADA-MIPI20-MICTOR adapter pinout (Continued)
