Technical specifications
IAR Debug Probes User Guide
I-jet®, I-jet Trace, and I-scope™
The MIPI-20 pinout for I-jet Trace CM is the same as for I-jet.
I-jet Trace A/R/M comes with two 60-pin flat cables that terminate in an adapter board
with a Mictor-38 male connector that is designed to plug in directly into the target board.
The Mictor connector allows for JTAG/SWD/cJTAG/SWO debugging as well as for up
to 16-bit wide ETM trace.
The adapter board also contains a standard MIPI-20 header for connecting to target
boards without the Mictor connection.
This is the Mictor-38 pinout for I-jet Trace A/R/M:
Signal Pin Pin Signal
12
34
GND 5 6 TRACECLK
TRIGIN 7 8 TRIGOUT
nSRST 9 10 EXTTRIG
TDO 1112VTREF
RTCK 13 14 VSUPPLY (not used)
TCK 1516TRACEDATA[07]
TMS 1718TRACEDATA[06]
TDI 1920TRACEDATA[05]
nTRST 2122TRACEDATA[04]
TRACEDATA[15] 23 24 TRACEDATA[03]
TRACEDATA[14] 25 26 TRACEDATA[02]
TRACEDATA[13] 27 28 TRACEDATA[01]
TRACEDATA[12] 29 30
TRACEDATA[11] 31 32
TRACEDATA[10] 33 34
TRACEDATA[09] 35 36 TRACECTL
TRACEDATA[08] 37 38 TRACEDATA[00]
Table 15: The Mictor-38 pinout for I-jet Trace A/R/M
