IBIS GmbH SiViB Record 1500 / Record Control Manual Page 5
IBIS Ingenieurbüro für Instandhaltungs- und Schwingungsmeß-Systeme GmbH
Reinheimer Str. 17, 64846 Groß-Zimmern, Germany; www.ibis-gmbh.de
Tel. +49 6071/42222, Fax +49 6071/71707, Email: info@ibis-gmbh.de
Hardware Installation
Wiring Terminals for Type 1501, 1511
Terminal
Function
1 + 24 V DC
2 Ground 24 VDC
3 Accelerometer 1 Signal
4 Accelerometer 1 Ground
5 Alarm A
6 Alarm B
7 Alarm C
8 Alarms Set Input (Set 1)
9 Machine Speed Input (1 pulse per rev)
10 +24 V DC Supply for alarm outputs
11 Ground alarms
12 Option Analog Out 0 – 10 Volt for mm/s for input 1
13 Option Analog Out 0 – 10 Volt for gSE for input 1
14 Ground for analog outputs
15 Ground for analog outputs
16 (1
st
upper
row)
AIN 1 (analogue input 1)
17 Analog GND
18 AIN 2.
19 Analog GND
20 AIN 3 or accelerometer 2 signal
21 Analog GND or accelerometer 2 ground
22 1501, 1511: AIN4
1502, 1512: Option Analog Out 0 – 10 Volt for mm/s input 2
23 1501, 1511: Analog GND
1502, 1512: Option Analog Out 0 – 10 Volt for gSE input 2
24 DIG IN 1 (digital input 1) / Event enable
25 DIG IN 2 (elapsed hour counter)
26 DIG IN 3 (tool change counter)
27 DIG IN 4 (store)
28 DIG GND
29 CAN Ser + (Option)
30 CAN Ser – (Option)
Description of terminal connections
1: +24 V DC supply
2: Ground supply
3: Accelerometer 1 Signal. For accelerometer with 4 mA constant current supply (ICP)
4: Accelerometer 1 ground
5: Alarm output A (Opto coupler output) max. 150 mA load (supply for opto couplers terminal 10 and
11 must be connected for use of all alarm outputs).
6: Alarm Output B (see above)
7: Alarm Output C (see above)
