Wiring Terminals for Type 1502, 1512
Terminal
Function
1 + 24 V DC
2 Ground 24 VDC
3 Accelerometer 1 Signal
4 Accelerometer 1 Ground
5 Alarm A
6 Alarm B
7 Alarm C
8 Alarms Set Input (Set 1)
9 Machine Speed Input (1 pulse per rev)
10 +24 V DC Supply for alarm outputs
11 Ground alarms
12 Option Analog Out 0 – 10 Volt for mm/s for input 1
13 Option Analog Out 0 – 10 Volt for gSE for input 1
14 Ground for analog outputs
15 Ground for analog outputs)
16 (1
st
upper
row)
AIN 1 (analogue input 1)
17 Analog GND
18 AIN 2.
19 Analog GND
20 Accelerometer 2 Signal
21 Accelerometer 2 Ground
22 Option Analog Out 0 – 10 Volt for mm/s for input 2
23 Option Analog Out 0 – 10 Volt for gSE for input 2
24 DIG IN 1 (digital input 1) / Event enable
25 DIG IN 2 (elapsed hour counter)
26 DIG IN 3 (tool change counter)
27 DIG IN 4 (store)
28 DIG GND
29 CAN Ser + (Option)
30 CAN Ser – (Option)
For further descriptions see above
