IBIS GmbH SiViB Record 1500 / Record Control Manual Page 51
IBIS Ingenieurbüro für Instandhaltungs- und Schwingungsmeß-Systeme GmbH
Reinheimer Str. 17, 64846 Groß-Zimmern, Germany; www.ibis-gmbh.de
Tel. +49 6071/42222, Fax +49 6071/71707, Email: info@ibis-gmbh.de
Annex
Technical Specification
Specifications
Units of Measurement: 1, 2 or 3 x vibration velocity v
RMS
and roller bearing condition gSE
4 or 2 x process parameters (0-10 Volt) or temperature (PT1000, KTY 84)
3 x digital inputs 24 VDC
1 x machine speed (1 pulse per rev)
Case: Plastic case IP20 for 35 mm DIN rail or base plate mounting
Dimensions 100 x 75 x 110 mm (WxHxD);
Inputs / Outputs: 30 screw terminals:
1 or 2 inputs for accelerometers; ICP supply
sensitivity 10, 100 or 500 mV/g
4 or 2 inputs for DC Volts (0 – 10 Volts) or
temperature (PT1000, KTY 84)
1 input for machine status / parameter set (Opto coupler)
1 input for trigger signal store data set
3 digital inputs 24 VDC (opto coupler)
3 Alarm outputs (opto coupler)
1 output sensor fault (opto coupler)
Serial interface
RS232C:
9-pin male; for Null-Modem-Cable to PC for configuration and download
Power supply: 24 VDC; approx. 250 mA
Ranges:
(using 100 mV/g
accelerometer)
vibration: 0,1 - 10 / 20 / 40 / 80 mm/s v
eff
bearing condition: 0,1 - 10 / 20 / 40 / 80 gSE
process variables: 0 – 10 VDC
temperature: 0 – 200 degrees Celsius
speed: 0 – 60 000 min
-1
(1 pulse per rev)
