IBM 4820 System Reference Guide

Condition description Resolution
Blocks of missing data on display
v Check that the LCD cable is securely
connected.
v Check that the controller cable of the host
system is securely connected.
v Run the 4820 Video Quality Test Pattern.
v If necessary, replace the cables.
v Replace the 4820 display, if necessary.
Magnetic stripe reader (MSR) malfunctioning
v Check that the cable is securely connected.
v Make sure the MSR is securely attached to
the display.
v Run the MSR test using the service diskette.
v Replace the MSR.
v For models 48D, 48T, refer to the IBM POS
Device Diagnostics, which came with the
POSS for Windows installation.
Keypad malfunctioning
v Check that the cable is securely connected.
v Make sure the keypad is securely attached to
the display.
v Run the keypad test using the service
diskette.
v Replace the keypad.
v For models 48D, 48T, refer to the IBM POS
Device Diagnostics, which came with the
POSS for Windows installation.
Pointing device malfunctioning
v Make sure the pointing device is securely
attached to the display.
v Run the pointing device test using the service
diskette.
v Replace the pointing device.
v For models 48D, 48T, refer to the IBM POS
Device Diagnostics, which came with the
POSS for Windows installation.
Troubleshooting common problems
B-4 4820 SurePoint Solution System Reference
