IBM BladeCenter HS22V 7871 User Manual

Replaceable components are of the following types:
v Consumable parts: Purchase and replacement of consumable parts (components,
such as batteries and printer cartridges, that have depletable life) is your
responsibility. If IBM acquires or installs a consumable part at your request, you
will be charged for the service.
v Tier 1 customer replaceable unit (CRU): Replacement of Tier 1 CRUs is your
responsibility. If IBM installs a Tier 1 CRU at your request, you will be charged
for the installation.
v Tier 2 customer replaceable unit: You may install a Tier 2 CRU yourself or
request IBM to install it, at no additional charge, under the type of warranty
service that is designated for your server.
v Field replaceable unit (FRU): FRUs must be installed only by trained service
technicians.
For information about the terms of the warranty and getting service and assistance,
see the Warranty Information document.
Index Description
CRU part
number
(Tier 1)
CRU part
number
(Tier 2)
FRU part
number
1 Cover (all models) 46C7341
2 Heat sink, microprocessor (Microprocessor 1) 46C7387
3
Microprocessor, Intel Xeon E5603 1.60 GHz/1066MHz-4MB
80W (quad core) (model A5x)
81Y5952
3
Microprocessor, Intel Xeon L5609 1.86 GHz/1066MHz
QPI-12MB 40W (quad core)
69Y0783
3
Microprocessor, Intel Xeon L5618 1.87 GHz/1066MHz
QPI-12MB 40W (quad core)
69Y4713
3
Microprocessor, Intel Xeon E5503 2.0 GHz/4.8GTps
QPI/800MHz-4MB 80W (dual core) (model D3x)
69Y0781
3
Microprocessor, Intel Xeon L5638 2.0 GHz/1333MHz
QPI-12MB 60W (six core)
69Y4715
3
Microprocessor, Intel Xeon E5506 2.13 GHz/800MHz-4MB 80W
(quad core)
46D1270
3
Microprocessor, Intel Xeon E5606 2.13 GHz/1066MHz-8MB
80W (quad core)
81Y5953
3
Microprocessor, Intel Xeon L5630 2.13 GHz/5.86GTps
QPI/1066MHz-12MB 40W (quad core)
59Y3691
3
Microprocessor, Intel Xeon E5607 2.26 GHz/1066MHz-8MB
80W (quad core) (model A7x)
81Y5954
3
Microprocessor, Intel Xeon L5640 2.26 GHz/5.86GTps
QPI/1333MHz-12MB 60W (six core) (model N2x)
49Y7054
3
Microprocessor, Intel Xeon E5507 2.26 GHz/4.8GTps
QPI/800MHz-4MB 80W (quad core) (model A4x)
69Y0782
3
Microprocessor, Intel Xeon E5620 2.40 GHz/5.86GTps
QPI/1066MHz-12MB 80W (quad core) (model G2x)
49Y7053
3
Microprocessor, Intel Xeon E5645 2.40 GHz/5.86GTps
QPI/1333MHz-12MB 80W (six core)
69Y4714
3
Microprocessor, Intel Xeon E5540 2.53 GHz/1066MHz-8MB
80W (quad core) (model B4x)
46D1265
42 BladeCenter HS22V Type 7871 and 1949: Problem Determination and Service Guide
