Figure 17. Hybrid conguration
The following table describes single MES upgrade possibilities from performance conguration to hybrid
congurations:
Table 3. MES upgrade from performance to hybrid
conguration
Target ->
Source
P (f)
24
NVMe
H1
(h, h)
12
NVM
e
1 X
52
HDD
H1
(h, f)
12
NVM
e
1 X
102
HDD
H2
(h, f)
12
NVM
e
2 X
102
HDD
H3 (h,
f)
12
NVMe
3 X
102
HDD
H4
(h, f)
12
NVM
e
4 X
102
HDD
H1 (f,
h)
24
NVMe
1 X 52
HDD
H1
(f, f)
24
NVM
e
1 X
102
HDD
H2 (f, f)
24
NVMe
2 X 102
HDD
H3 (f,
f)
24
NVMe
3 X
102
HDD
H4
(f, f)
24
NVM
e
4 X
102
HDD
P (h) Y Y Y Y Y Y
P (f) Y Y Y Y Y
P(h) = Performance half populated
P(f) = Performance full populated
Refer to the following steps to congure hybrid solution using 5141-FN2 and 5147-102 enclosures:
Chapter 1. Servicing (customer task)
17
