Table 8. NVMe flash drive capacity options
Feature code Description
AJP4 3.84 TB 2.5-inch PCIe Gen4 NVMe flash drive
AJP5 7.68 TB 2.5-inch PCIe Gen4NVMe flash drive
AJP6 15.36 TB 2.5-inch PCIe Gen4 NVMe flash drive
AJPT 30 TB 2.5-inch PCIe Gen4 NVMe flash drive
This procedure is only applicable to an ESS 3500 capacity conguration that includes four 3.8TB NVMe
drives in its 5141-FN2 server enclosure as the system's initial conguration for journal information. When
the MES is successfully completed, the ESS 3500 solution will be converted into hybrid solution to also
include 20 NVMe flash drives for customer data storage as seen below.
Figure 22. Capacity conguration
The following table describes single MES upgrade possibilities from capacity to hybrid conguration:
34
IBM Elastic Storage System 5147-10 Storage Enclosure: Service Guide
