ess3200rw3a.gpfs.ess:
mmvdisk: RG003LG001VS009: size 6299740 MB
mmvdisk: RG003LG002VS009: size 6299740 MB
mmvdisk: RG003LG003VS009: size 6299740 MB
mmvdisk: RG003LG004VS009: size 6299740 MB
mmvdisk: Extending Allocation Map
mmvdisk: Checking Allocation Map for storage pool system
mmvdisk: Completed adding disks to file system ess3200rw3fs1.
Mon Aug 16 14:22:47 MST 2021
• Verify that the VDisk set is added to the le system.
# mmvdisk vs list --vs vs_fs3200_2 ;date
member vdisks
vdisk set count size raw size created file system and attributes
-------------- ----- -------- -------- ------- --------------------------
vs_fs3200_2 4 6152 GiB 7820 GiB yes ess3200rw3fs1, DA1, 8+2p, 4 MiB,
dataAndMetadata, system
declustered capacity all vdisk sets defined
recovery group array type total raw free raw free% in the declustered array
--------------- ----------- ---- --------- -------- ----- ------------------------
ess3200_78E400K DA1 NVMe 76 TiB 15 TiB 20% vs_fs3200_1, vs_fs3200_2
vdisk set map memory per server
node class available required required per vdisk set
------------------------------ --------- -------- ----------------------
ess3200_x86_64_mmvdisk_78E400K 120 GiB 7080 MiB vs_fs3200_1 (1074 MiB), vs_fs3200_2
(1077 MiB)
Mon Aug 16 14:24:01 MST 2021
The customer can use the new space by creating new vdisk sets from the available space. When
the vdisk sets are added to the existing le system (if needed), the restripe operation can be
run. For more information, see IBM Spectrum Scale: Administration Guide. When you are adding a
vdisk set to a le system, the default TRIM setting is "no" irrespective of the TRIM settings of the
existing vdisk sets. Issue the mmvdisk lesystem add command with the --trim {auto|no} option
to select TRIM settings when you are adding a vdisk set to a le system. For more information, see
Enable, disable, extend, and view TRIM settings on an existing declustered array and le system in
the Managing TRIM support for storage space reclamation chapter in IBM Spectrum Scale RAID:
Administration Guide.
Re-cabling guidelines from single SAS adapter pair to dual SAS adapter
pairs
This concurrent MES procedure explains how to convert cabling between 5141-FN2 and 5147-102
storage enclosures using single SAS adapter pair to dual SAS adapter pairs for up to four storage
enclosures.
The procedure assume the second SAS adapter pair needs to be added rst, which is the Adapter MES by
itself, as part of this re-cabling procedure.
The following steps are the high-level flow of the procedure:
1. Perform adapter MES in Canister A/1 to add the second SAS adapter.
2. Restore the original network cabling to Canister A/1.
3. Restart GPFS and restore lesystem mounts in Canister A/1.
4. Run common system health check by using the SSR utility.
5. Perform adapter MES in Canister B/2 to add the second SAS adapter.
6. Restore the original network cabling to Canister B/2.
7. Restart GPFS and restore lesystem mounts in Canister B/2.
8. Alter cable connections in Canister A/1 to utilize both SAS adapters.
9. Alter cable connections in Canister B/2 to utilize both SAS adapters.
Chapter 1. Servicing (customer task)
41
