Table 9. MES upgrade from capacity to hybrid conguration
Target ->
Source
H1 (h)
4 NVMe
20 NVMe
1 X 52 HDD
H1 (f)
4 NVMe
20 NVMe
1 X 102 HDD
H2 (f)
4 NVMe
20 NVMe
3 X 102 HDD
H3 (f)
4 NVMe
20 NVMe
4 X 102 HDD
H4 (f)
4 NVMe
20 NVMe
4 X 102 HDD
C1 (h)
4 NVMe +52
HDD
Y
C1 (f) Y
C2 (f) Y
C3 (f) Y
C4 (f) Y
C n (h) = Capacity, n x half populated 5147-102
C n (f) = Capacity, n x full populated 5147-102
H n (h)= Hybrid (4 + 20 PVMe MES) + n x half populated 5147-102
H n (f)= Hybrid (4 + 20 PVMe MES) + n x full populated 5147-102
Refer to the following steps to add NVMe drives to an existing ESS 3500 capacity conguration:
1. Before beginning the MES upgrade, make sure the Technical Delivery Assessment (TDA) procedure is
nished. This step is mandatory if you did not purchase MES and attend the TDA with sales.
2. Ensure that the system is running at least ESS 6.1.5.0 for the storage MES.
3. Move the quorum to other supported nodes in the system if losing quorum on each canister server
causes an issue with the customer conguration during MES upgrade.
4. Identify the 5141-FN2 server enclosure to be upgraded.
5. Remove the drive llers from the slots 3-12 and 15-24.
6. Verify that the 20 new NVMe flash drive FRUs have the same capacity as the four original 3.8TB
NVMe flash drives.
7. Insert the 20new NVMe drive FRUs into slots 3-12 and 15-24.
Important: Do not move the original four NVMe drives to different slots.
8. Verify the new 24 NVMe disk topology on both the canisters by issuing the following command:
# mmvdisk server list --disk-topology --node-class <node class name>
Matching Metric identies any unexpected results in disk topology.
# date; mmvdisk server list --disk-topology --node-class
ess3200_x86_64_mmvdisk_78E400K
Fri Aug 13 16:37:09 MST 2021
node needs matching
number server attention metric disk topology
------ -------------------------------- --------- -------- -------------
6 ess3200rw3a-hs.gpfs.ess yes 95/100 ESS 3200 FN1 24 NVMe
7 ess3200rw3b-hs.gpfs.ess yes 95/100 ESS 3200 FN1 24 NVMe
If Matching Metric is not 100/100, use the following commands to determine what needs your
attention:
# mmvdisk server list -N ess3200rw3a-hs.gpfs.ess --disk-topology -L
Chapter 1. Servicing (customer task)
35
