IBM Elastic Storage System 5147-102

drive a8241014065c 78E400K SN5ASN5A SN5ASN5A ess3200rw3a-
hs Rack Bodhi-Rack-1520 U25-26, Enclosure 5141-FN1-78E400K Drive 9
• Rerun the following command if some drives failed to update to the current level.
# mmchfirmware --type <component type>
11. Verify that the drives are formatted correctly. For the newly added drives, the format column must
show 4 KiB + 0 B. You must reformat the added drives if the drives are formatted as 4 KiB + 8 B. To
format added drives as 4 KiB + 0 B, see Formatting drives example.
# nvme list
Example:
# nvme list
Node SN Model Namespace
Usage Format FW Rev
---------------- -------------------- ---------------------------------------- ---------
-------------------------- ---------------- --------
/dev/nvme0n1 2024296F1E08 Micron_7300_MTFDHBA960TDF 1
960.20 GB / 960.20 GB 4 KiB + 0 B 95420100
/dev/nvme10n1 S54KNE0NA00461 3.84TB NVMe Tier-1 Flash 1
3.84 TB / 3.84 TB 4 KiB + 0 B SN5ASN5A
/dev/nvme11n1 S54KNE0NA00537 3.84TB NVMe Tier-1 Flash 1
3.84 TB / 3.84 TB 4 KiB + 0 B SN5ASN5A
/dev/nvme12n1 S54KNE0NA00247 3.84TB NVMe Tier-1 Flash 1
3.84 TB / 3.84 TB 4 KiB + 0 B SN5ASN5A
/dev/nvme13n1 S54KNE0NA00465 3.84TB NVMe Tier-1 Flash 1
3.84 TB / 3.84 TB 4 KiB + 0 B SN5ASN5A
/dev/nvme14n1 S54KNE0NA00117 3.84TB NVMe Tier-1 Flash 1
3.84 TB / 3.84 TB 4 KiB + 0 B SN5ASN5A
/dev/nvme15n1 S54KNE0NA00113 3.84TB NVMe Tier-1 Flash 1
3.84 TB / 3.84 TB 4 KiB + 8 B SN5ASN5A
/dev/nvme16n1 S54KNE0NA00135 3.84TB NVMe Tier-1 Flash 1
3.84 TB / 3.84 TB 4 KiB + 8 B SN5ASN5A
/dev/nvme17n1 S54KNE0NA00127 3.84TB NVMe Tier-1 Flash 1
3.84 TB / 3.84 TB 4 KiB + 8 B SN5ASN5A
/dev/nvme18n1 S54KNE0NA00412 3.84TB NVMe Tier-1 Flash 1
3.84 TB / 3.84 TB 4 KiB + 8 B SN5ASN5A
/dev/nvme19n1 S54KNE0NA00118 3.84TB NVMe Tier-1 Flash 1
3.84 TB / 3.84 TB 4 KiB + 8 B SN5ASN5A
/dev/nvme1n1 202228CD166E Micron_7300_MTFDHBA960TDF 1
960.20 GB / 960.20 GB 4 KiB + 0 B 95420100
/dev/nvme20n1 S54KNE0NA00153 3.84TB NVMe Tier-1 Flash 1
3.84 TB / 3.84 TB 4 KiB + 8 B SN5ASN5A
/dev/nvme21n1 S54KNE0NA00159 3.84TB NVMe Tier-1 Flash 1
3.84 TB / 3.84 TB 4 KiB + 8 B SN5ASN5A
/dev/nvme22n1 S54KNE0NA00307 3.84TB NVMe Tier-1 Flash 1
3.84 TB / 3.84 TB 4 KiB + 8 B SN5ASN5A
/dev/nvme23n1 S54KNE0NA00156 3.84TB NVMe Tier-1 Flash 1
3.84 TB / 3.84 TB 4 KiB + 8 B SN5ASN5A
/dev/nvme24n1 S54KNE0NA00141 3.84TB NVMe Tier-1 Flash 1
3.84 TB / 3.84 TB 4 KiB + 8 B SN5ASN5A
/dev/nvme25n1 S54KNE0NA00131 3.84TB NVMe Tier-1 Flash 1
3.84 TB / 3.84 TB 4 KiB + 8 B SN5ASN5A
/dev/nvme2n1 S54KNE0NA00269 3.84TB NVMe Tier-1 Flash 1
3.84 TB / 3.84 TB 4 KiB + 0 B SN5ASN5A
/dev/nvme3n1 S54KNE0NA00259 3.84TB NVMe Tier-1 Flash 1
3.84 TB / 3.84 TB 4 KiB + 0 B SN5ASN5A
/dev/nvme4n1 S54KNE0NA00485 3.84TB NVMe Tier-1 Flash 1
3.84 TB / 3.84 TB 4 KiB + 0 B SN5ASN5A
/dev/nvme5n1 S54KNE0NA00255 3.84TB NVMe Tier-1 Flash 1
3.84 TB / 3.84 TB 4 KiB + 0 B SN5ASN5A
/dev/nvme6n1 S54KNE0NA00256 3.84TB NVMe Tier-1 Flash 1
3.84 TB / 3.84 TB 4 KiB + 0 B SN5ASN5A
/dev/nvme7n1 S54KNE0NA00459 3.84TB NVMe Tier-1 Flash 1
3.84 TB / 3.84 TB 4 KiB + 0 B SN5ASN5A
/dev/nvme8n1 S54KNE0NA00532 3.84TB NVMe Tier-1 Flash 1
3.84 TB / 3.84 TB 4 KiB + 0 B SN5ASN5A
/dev/nvme9n1 S54KNE0NA00246 3.84TB NVMe Tier-1 Flash 1
3.84 TB / 3.84 TB 4 KiB + 0 B SN5ASN5A
12. Issue the essinstallcheck command from both canisters and ensure that no error is shown
before you proceed to the next step.
# essinstallcheck -N <node list>
38
IBM Elastic Storage System 5147-10 Storage Enclosure: Service Guide
