Table 12. Enclosure physical characteristics (continued)
Enclosure type Model Height Width Depth Maximum weight
Drive ready
(without
drives)
Fully
congured
(with drives)
Expansion
enclosure (12
LFF drive slots)
FlashSystem
5000
( 2072-12G /
2072-F12 )
FlashSystem
5000 (2072-
E12)
8.7 cm (3.4 in) 48.3 cm (19.0
in)
55.6 cm (21.9
in)
16.4 kg (36.1
lb)
26.7 kg (58.9
lb)
Expansion
enclosure (24
SFF drive slots)
FlashSystem
5000
2072-24G /
2072-F24 )
FlashSystem
5000 (2072-
E24)
8.7 cm (3.4 in) 48.3 cm (19.0
in)
55.6 cm (21.9
in)
16.7 kg (36.8
lb)
25.0 kg (55.1
lb)
Expansion
enclosure (92
drive slots)
FlashSystem
5000
( 2072-92G /
2072-F92 )
FlashSystem
5000 (2072-
E92)
222.2 mm
(8.75 in.)
483 mm (19.0
in.)
968 mm (38.1
in.)
67 kg (147.7 lb) 135 kg (297 lb)
Attention: To avoid potential equipment damage during transport and subsequent loss of data,
see Procedure: Transporting a 5U 92-drive expansion enclosure. The procedure describes what to
do for the following situations.
• When you are powering off a 92F, 92G, or an A9F 5U expansion enclosure because you intend to
transport it to another location
• When you intend to move a rack that contains a 92F, 92G, or an A9F 5U expansion enclosure
The procedure describes how to remove each drive from the 5U enclosure and transport the
enclosure. Removing the drives prevents damage to the drives and makes the lighter enclosure
easier to move.
Warning: 2072-92G / 2072-F92 or 2072-E92 (5U) expansion enclosure models need 968 mm
from the rack front post to the back of the cable management arm (CMA). There are racks that will
not provide sufcient space to close the rear door. In addition, allow 905 mm from the front post
to the back of the enclosure. To allow space for the power cables, provide 60 - 70 mm from the
back of the enclosure.
Figure 3 on page 10 shows the rack space requirements for the 5U models.
Chapter 2. Environmental requirements
9
