Chapter 1. General description 9
The Power 780 operator interface controls, located on the front panel of the primary I/O
drawer, consist of a power ON/OFF button with a POWER indicator, an LCD display for
diagnostic feedback, a RESET button, and a disturbance or system attention LED.
1.4.3 Minimum features
Each system has a minimum feature set in order to be valid. Table 1-3 shows the minimum
system configuration for a Power 770.
Table 1-3 Minimum features for Power 770 system
Power 770 minimum features Additional notes
1x CEC enclosure (4U) 1x System Enclosure with IBM Bezel (FC EB85) or OEM
Bezel (FC EB86)
1x Service Processor (FC EU09)
1x DASD Backplane (FC 5652)
2x Power Cords (two selected by customer)
– 2x A/C Power Supply (FC 5532)
1x Operator Panel (FC EC53)
1x Integrated Multifunction Card options (one of these):
– Dual 10 Gb Copper and Dual 1 Gb Ethernet (FC 1768)
– Dual 10 Gb Optical and Dual 1 Gb Ethernet (FC 1769)
1x primary operating system (one
of these)
AIX (FC 2146)
Linux (FC 2147)
IBM i (FC 2145)
1x Processor Card 0 to 12-core, 4.42 GHz processor card (FC EPM0)
0 to 16-core, 3.72 GHz processor card (FC EPM2)
4x Processor Activations
(quantity of four for one of these)
One Processor Activation for processor feature FC EPM0
(FC EPMA)
One Processor Activation for processor feature FC EPM2
(FC EPMB)
2x DDR3 Memory DIMMs
(one of these)
0 - 32 GB (4 X 8 GB), 1066 MHz (FC EM40)
0 - 64 GB (4 X 16 GB), 1066 MHz (FC EM41)
0 - 128 GB (4 X 32 GB), 1066 MHz (FC EM42)
0 - 256 GB (4 X 64 GB), 1066 MHz (FC EM44)
32x Activations of 1 GB DDR3
POWER7+ memory
FC EMA2
32x Activations of 100 GB DDR3 -
POWER7+ memory
FC EMA3
For AIX and Linux: 1x disk drive
For IBM i: 2x disk drives
Formatted to match the system Primary O/S indicator selected,
or if using a Fibre Channel attached SAN (indicated by FC 0837)
a disk drive is not required.
1X Language Group
(selected by the customer)
-
