Chapter 2. Architecture and technical overview 73
2.8.6 Graphics accelerator adapters
The IBM Power 770 and Power 780 support up to eight graphics adapters (Table 2-14). They
can be configured to operate in either 8-bit or 24-bit color modes. These adapters support
both analog and digital monitors, and do not support hot-plug installation. The total number of
graphics accelerator adapters in any one partition cannot exceed four.
Table 2-14 Available graphics accelerator adapters
5767 5767 2-Port 10/100/1000 Base-TX
Ethernet PCI Express adapter
PCIe Full height
Short
AIX, IBM i,
Linux
5768 5768 2-Port Gigabit Ethernet-SX PCI
Express adapter
PCIe Full height
Short
AIX, IBM i,
Linux
5769 5769 10 Gigabit Ethernet-SR PCI
Express adapter
PCIe Full height
Short
AIX, Linux
5772 576E 10 Gigabit Ethernet-LR PCI
Express adapter
PCIe Full height
Short
AIX, IBM i,
Linux
5899 576F 4-Port 1Gb Ethernet Adapter PCIe Full height AIX, IBM i,
Linux
EC28 EC27 2-Port 10Gb Ethernet/FCoE SFP+
Adapter with Optics
PCIe Low profile AIX, Linux
EC30 EC29 2-Port 10Gb Ethernet/FCoE SFP+
Adapter with Optics
PCIe Low profile AIX, Linux
EN0H 2B93 PCIe2 4-port (10Gb FCoE and
1GbE) SR&RJ4 Adapter
PCIe Full height AIX, Linux,
IBM i
Feature
code
CCIN Adapter description Slot Size OS
support
Feature
code
CCIN Adapter description Slot Size OS
support
2849
a
a. Supported, but is no longer orderable.
2849 POWER GXT135P Graphics
Accelerator with Digital Support
PCI-X Short AIX,
Linux
5748 5748 POWER GXT145 PCI Express
Graphics Accelerator
PCIe Short AIX,
Linux
