1. Ensure that you have the electrostatic discharge (ESD) wrist strap attached. If not, attach it now.
2. Remove the two shipping screws (A) (if present) that secure the system to the rack.
Note: Replacing the shipping screws is optional but should be done in geographic areas that are
prone to seismic activity.
3. Pull the cover away from the system. The cover has an indentation where you can hold onto it more
easily.
Removing the front cover from a stand-alone 8286-41A system
Use this procedure to remove the cover from a stand-alone 8286-41A system so that you can access
components or perform service.
To remove the front cover, complete the following steps:
1. Open the front door.
2. Ensure that you have the electrostatic discharge (ESD) wrist strap attached. If not, attach it now.
3. Pull the blue tab (A) to open the bezel door.
4. Push the blue latch (B) located above the USB ports, in the direction shown on the latch and then pull
the front cover away from the system.
Figure 130. Removing the front cover
Common procedures for installing, removing and replacing disk drives or solid-state drives 149
