Installing the service access cover on a 5148-21L, 5148-22L, 8247-21L,
8247-22L, 8247-42L, 8284-21A, 8284-22A, 8286-41A, or 8286-42A system
Use this procedure to install the service access cover.
Installing the service access cover on a rack-mounted 5148-21L, 5148-22L,
8247-21L, 8247-22L, 8247-42L, 8284-21A, 8284-22A, 8286-41A, or 8286-42A system
Use this procedure to install the service access cover on a rack-mounted 5148-21L, 5148-22L, 8247-21L,
8247-22L, 8247-42L, 8284-21A, 8284-22A, 8286-41A, or 8286-42A system.
To install the service access cover on a rack-mounted system, complete the following steps:
1. Ensure that you have the electrostatic discharge (ESD) wrist strap attached. If not, attach it now.
2. Slide the cover (B) on to the system unit.
3. Close the latch release (A) by pushing it in the direction shown.
Figure 145. Removing the service access cover
Common procedures for installing, removing and replacing disk drives or solid-state drives 161
