d. Verify that the disk drive or solid-state drive that you installed is shown on this display.
7. To configure the newly installed disk drive or solid-state drive, see “Configuring a disk drive or
solid-state drive for use in an Linux system or Linux logical partition” on page 118.
Removing and replacing a disk drive or solid-state drive in the
5148-21L, 5148-22L, 8247-21L, 8247-22L, 8284-21A, or 8284-22A
Find information about removing and replacing a serial-attached SCSI (SAS) disk drive or a solid-state
drive (SSD) in a system.
If you are removing and replacing a disk drive or solid-state drive in a 5887 disk drive enclosure or
5147-024, ESLL, or ESLS storage enclosure, see Removing and replacing a disk drive or solid-state drive
in the 5887 disk drive enclosure(http://www.ibm.com/support/knowledgecenter/POWER8/p8hal/
p8hal_5887_rnr_kickoff.htm) or Removing and replacing a disk drive or solid-state drive in the 5147-024,
ESLL, or ESLS storage enclosure storage enclosure(http://www.ibm.com/support/knowledgecenter/
POWER8/p8hal/p8hal_eslx_rnr_kickoff.htm).
Removing and replacing a disk drive or solid-state drive in the
5148-21L, 5148-22L, 8247-21L, 8247-22L, 8284-21A, or 8284-22A with
the system power turned off
Learn how to remove and replace a disk drive or solid-state drive (SSD) in a system with the system
power turned off.
To remove and replace a disk drive or solid-state drive in a system, complete the following steps:
1. “Preparing the 5148-21L, 5148-22L, 8247-21L, 8247-22L, 8284-21A, or 8284-22A system to remove and
replace a disk drive or solid-state drive with the power turned off” on page 39.
2. “Removing a disk drive or solid-state drive from the 5148-21L, 5148-22L, 8247-21L, 8247-22L,
8284-21A, or 8284-22A system with the power turned off” on page 42.
3. “Replacing a disk drive or solid-state drive in the 5148-21L, 5148-22L, 8247-21L, 8247-22L, 8284-21A,
or 8284-22A system with the power turned off” on page 45.
4. “Preparing the 5148-21L, 5148-22L, 8247-21L, 8247-22L, 8284-21A, or 8284-22A system for operation
after removing and replacing a drive with the power turned off” on page 47.
Display Hardware Status
Type option, press Enter.
1=Display hardware resource information details
OPT Name PCI/SCSI Location Description Status
--- ------ -------------------------- ------------------------- ----------------
0000:01:00.0/0: PCI-E SAS RAID Adapter Operational
0000:01:00.0/0:0:0:0 Advanced Function SSD Active
0000:01:00.0/0:0:1:0 Advanced Function SSD Active
0000:01:00.0/0:0:2:0 Advanced Function SSD Active
0000:01:00.0/0:0:3:0 Advanced Function SSD Active
0000:01:00.0/0:0:4:0 Advanced Function SSD Active
0000:01:00.0/0:0:5:0 Advanced Function SSD Active
0000:01:00.0/0:0:6:0 Advanced Function SSD Active
0000:01:00.0/0:0:8:0 Enclosure Active
0000:01:00.0/0:0:9:0 Enclosure Active
0001:01:00.0/1: PCI-E SAS RAID Adapter Operational
0001:01:00.0/1:0:3:0 Advanced Function SSD Remote
0001:01:00.0/1:0:4:0 Advanced Function SSD Remote
0001:01:00.0/1:0:5:0 Advanced Function SSD Remote
More...
e=Exit q=Cancel r=Refresh t=Toggle f=PageDn b=PageUp
Figure 37. Example Display Hardware Status
38 Disk drives or solid-state drives
