IBM SAN128B-7 User Manual

Power supply specications (per PSU)
Power Supply
Model
Maximum
Output
Power
Rating
(DC)
Input
Voltage
Input Line
Frequency
Maximum
Input
Current
Input
Line
Protectio
n
Maximum Inrush
Current
XBR-1100WPSAC-
F
1100W 100–240
VAC
(nominal)
90–264
VAC (range)
50/60 Hz
(nominal)
47–63 Hz
(range)
~12.0A–
5.0A
Both AC
lines are
fused
40A peak @ 240 VAC
during cold startup at
25°C ambient
XBR-1100WPSAC-
R
1100W 100–240
VAC
(nominal)
90–264
VAC (range)
50/60 Hz
(nominal)
47–63 Hz
(range)
~12.0A–
5.0A
Both AC
lines are
fused
40A peak @ 240 VAC
during cold startup at
25°C ambient
Data port specications (Fibre Channel)
Name Port
Numbers
Media Type Description
SAN128B-
7 switch
0 to 95 8, 10, 16, 32, or 64G SFP+
optical ports
Can be an F_Port, E_Port, EX_Port, D_Port, or
AE_Port
96 to 127 16x (64G) DD optical ports Can be an F_Port, E_Port, EX_Port, D_Port, or
AE_Port
Fibre Channel data transmission ranges
Port Speed
(G)
Cable Size
(Microns)
Short Wavelength
(SWL)
Long Wavelength
(LWL)
Extended Long
Wavelength (ELWL)
8 50 50m (164 ft) (OM2)
150m (492 ft) (OM3)
190m (623 ft) (OM4)
N/A N/A
62.5 21m (68 ft) N/A N/A
9 N/A 10 km (6.2 miles) N/A
10 50 82m (269 ft) (OM2)
300m (984 ft) (OM3)
550m (1804 ft) (OM4)
N/A N/A
62.5 33m (108 ft) N/A N/A
9 N/A 10 km (6.2 miles) N/A
78 IBM Storage Networking SAN128B-7: SAN128B-7 Installation, Service, and User Guide
