Port Speed
(G)
Cable Size
(Microns)
Short Wavelength
(SWL)
Long Wavelength
(LWL)
Extended Long
Wavelength (ELWL)
16 50 35m (115 ft) (OM2)
100m (328 ft) (OM3)
125m (410 ft) (OM4)
N/A N/A
62.5 15m (49 ft) N/A N/A
9 N/A 10 km (6.2 miles) 25 km (15.5 miles)
32 50 70m (230 ft) (OM3)
100m (328 ft) (OM4)
N/A N/A
62.5 N/A N/A N/A
9 N/A 10 km (6.2 miles) 25 km (15.5 miles)
64 50 70m (230 ft) (OM3)
100m (328 ft) (OM4 and
OM5)
N/A N/A
62.5 N/A N/A N/A
9 N/A N/A N/A
Serial port specications (pinout RJ-45)
Pin
Signal Description
1 Not supported N/A
2 Not supported N/A
3 TXD Transmit data (output from
SAN128B-7)
4 GND Logic ground
5 GND Logic ground
6 RXD Receive data (input into
SAN128B-7)
7 Not supported N/A
8 Not supported N/A
Note: These specications are for the serial connector on IBM platforms only.
Appendix A. Product
specications 79
