To install a DIMM, complete the following procedure.

1. To help you work safely with Storwize V7000 Unified file modules, read the

safety information in “Safety” on page xi, “Safety statements” on page xiii,

and “Installation guidelines” on page 54.

2. Remove riser-card assembly 1, as described in “Removing a PCI riser-card

assembly” on page 99.

DIMM 17

DIMM 16

DIMM 15

DIMM 14

DIMM 13

DIMM 12

DIMM 11

DIMM 10

DIMM 8

DIMM 7

DIMM 6

DIMM 5

DIMM 4

DIMM 3

DIMM 2

DIMM 1

CH2

CH1

CH0

CH2

CH1

CH0

Microprocessor 2

Microprocessor 1

DIMM 9

DIMM 18

sonas236

Figure 38. DIMM locations for the Storwize V7000 Unified System x3650 M3 server

132 Storwize V7000 Unified: Problem Determination Guide Version
