SurePOS 500 4846-XX5 Technical Reference
Page 17 of 63
• AC ’97 compliant audio
• Supports 44.1K/48K/96K/192KHz DAC Independent Sample Rate
• All ADCs Support 48K/192KHz Independent Sample Rate
• 1W + 1W amplifier
PC Card Support (TI PCI140A) (X6X models only)
• Support for 1 Type II 5V/3.3V PC Card or 3.3V CardBus Cards
• Hot insertion/removal support
• Register-compatible with the Intel⎢ 82365SL-DF and 82365SL ExCA controllers
Secondary Video Adapter - ATI Radeon 7000 graphics processor
• 2D/3D capability, supports 3D resolutions (32-bit color) up to 2048x1536
• 32MB DDR onboard memory
• Better 3D performance (than base video)
• PCI 2.2 compliant : PCI-33
Touch
• ELO-based Infra-redesign
• RS232 interface to touch, mouse emulation
• Flashable firmware via USB
Touch Specifications
Attribute Specification
Technology Modified ELO Infra-red
Calibration Not required
Input Method Finger, stylus (8mm diameter min.)
Controller Resolution 1024x1024
Accuracy (std dev) 0.080-in.
Accuracy (max err)
0.047-in. (96%)
0.222-in (4%)
Drift None
Glass Finish Anti-glare
Transmissiveness 92%
Travel N/A
Touch Activation Force None
2.11 Component specifications
2.11.1 4GB Modular Flash Drive
Characteristic Specification
Interface USB 2.0
Data Reliability < 1 non-recoverable error in 10
14
bits read
Performance 20Mbps read / 10Mps write
2.11.2 Hard Disk Drive
Characteristics Specification
Form Factor 3.5-in
Formatted Capacity (GB) 80GB or greater
Interface SATA II, up to 3.0Gb/s
Rotational Speed 7200 rpm
