SurePOS 500 4846-XX5 Technical Reference
Page 5 of 63
1.0 Introduction
1.1 Highlights
The SurePOS 500 system units with integrated touch screens will help you easily create the right solution for your
business.
The SurePOS 500 Series models offer:
• An Intel Celeron D 326 (2.53 GHz) processor
• 512MB of DDR2 memory standard, upgradeable to 1 GB, 1.5GB, or 2GB.
• 8 to 128 MB UMA video memory
• A 80 GB SATA II HDD or greater
• 15" (12.1" and 17” optional) Infrared (IR) touch
• Enhanced wireless integration kit providing coverage and flexibility to meet most country-specific wireless
requirements by utilizing USB technology (USB wireless Dongle not included). The Performance multimedia
models also offer the capability to add wireless support via PC card slot
• Enhanced systems management
• Port enhancements, including powered 12V and 24V USB 2.0 ports, standard
• A wide range of optional features including receipt printers, displays, and trays to keep the counter neat.
1.2 Models
Model Base/Admin Model WEPOS
Bundled
Printer
Audio/PC Card
function
Warranty
545 Base No No No Depot
565 Base No No Yes Depot
E45 Base Yes No No Depot
E65 Base Yes No Yes Depot
54Z Admin of 545 No No No IOR 24x7
56Z Admin of 565 No No Yes IOR 24x7
E4Z Admin of E45 Yes No No IOR 24x7
E6Z Admin of E65 Yes No Yes IOR 24x7
P45 Admin of 545 No Yes No IOR 24x7
P65 Admin of 565 No Yes Yes IOR 24x7
1.3 Specifications
4846 Model 545 4846 Model 565
Processor 2.53Ghz Intel 326 Celeron D
FSB Speed 533/800 Mhz Celeron/Pentium4
Chipset Intel 915GV / ICH6
BIOS Award
Main Memory 512MB – 1GB DDR2 DIMM, 2 slots, (2 GB max)
Video
Integrated 2D/3D Intel graphics controller
(simultaneous support only for CRT output)
Secondary Video Adapter ATI Radeon 7000
LCD
One of the following:
800x600 12.1-in TFT (2 bulb)
1024x768 15-in TFT (2 bulb)
