Item # 8415 FRUs FRU# CRU
6 Diskette drive, 3.5 1.44 MB (models) 76H4091 *
7 Hard disk drive, 40 GB EIDE (models) 19K1568 *
8 System board, 10/100 E-net, no POV (models) 73P0595 **
8 System board, 10/100 E-net, no POV (supports Prescott CPU)
(models)
13R8926 **
8 System board, 10/100 E-net, no POV (models) 88P5837 **
9 256 MB SDRAM (models) 31P9121 *
9 512 MB SDRAM (models) 31P9122 *
10 Intel P4 2.8 GHz (models) 74P1631 **
10 Intel P4 3.0 GHz Prescott (models) 19R0294 **
11 Fan sink (models) 32P4004 **
11 Fan Sink (for Prescott only) (models) 13R9195 **
11 P4 mounting assembly (all models) 48P6726 *
12 Power supply, 230W (model) 74P4300 N
12 Power supply, 230W (China) (models) 74P4301 N
13 Chassis assembly (all models) 59P8542 N
The FRUs listed in the following table are not illustrated.
8415 FRUs FRU# CRU
Speaker assembly (all models) 00N5151 *
Front bezel release (all models) 25P0069 *
Front bezel blanks kit (all models) 25P0068 *
5.25 EMC shield (all models) 19K5548 *
Cable, Diskette drive (all models) 59P8568 *
Cable clip (all models) 59P8584 *
Cable, IDE (ATA66 2 drop) (all models) 37L5098 *
2 drop (close spacing) ATA 66/100 cable w/ pull tabs (all models) 59P8571 *
2 drop (large spacing) ATA 66/100 cable w/ pull tabs (all models) 59P8572 *
Retainer, cards I/O (all models) 59P8564 *
Universal adapter bracket (3.5 - 5.25) (all models) 32P4743 *
Fan assembly, 80 mm, fixed speed (models with 3.06GHz microprocessor or
greater)
22P4447 *
Misc. hardware kit (all models) 09N5764 *
Cable, CDROM audio (all models) 75H9219 *
Rubber foot (all models) 03K9655 *
Hard disk drive bracket assembly (all models) 59P8543 *
Hard disk drive tray (dampened) (all models) 59P8549 *
Cable, dual USB 2.0 (all models) 49P4365 *
Control panel assembly (all models) 59P8545 *
Audio cable assembly (ATA) (all models) 49P1933 *
PCMCIA assembly (all models) 59P8587 *
230 Hardware Maintenance Manual
