Item # 8430 FRUs FRU# CRU
11 Pivot lock, 3.5 Diskette drive (all models) 24P9876 *
12 Chassis assembly (all models) 88P5924 **
13 Power supply, 200W (models KUA KAA KNA KJA KGA) 74P4305 N
13 Power supply, 200W (China) 74P4306 N
14 Link bracket (all models) 88P5918 *
15 I/O cam bracket (all models) 24P9869 *
16 Air duct w/o fan (all models) 88P5922 *
The FRUs listed in the following table are not illustrated.
8430 FRUs FRU# CRU
Cable, C2 (squal) 09K9827 *
5.25 EMC shield (all models) 19K5548 *
Retention kit (all models) 88P5915 *
Planar shield kit (all models) 88P5931 *
Cable, Diskette drive (all models) 88P5930 *
Optical cable, ATA66 (all models) 88P5929 *
Cable, Hard disk drive (all models) 88P5928 *
Cable, SATA (all models) 88P5927 *
Service label (all models) 88P5926 *
Bezel kit (all models) 88P5923 *
Fan bracket assembly (all models) 88P5921 *
Korean label 13R9162 *
Misc. hardware kit (all models) 24P9878 *
Cable, CDROM audio (all models) 75H9219 *
Keylock assembly, random 88P5920 *
Vertical stand, black (all models) 88P5917 *
Bottom foot (all models) 03K9655 *
Hard disk drive mounting bracket assembly (all models) 88P5916 **
Cable assembly, power/LED (all models) 37L5092 *
Cable, USB 2.0 (all models) 49P4365 *
Battery, 3.0 V (all models) 33F8354 *
Monitor cable (all models) 19R3015 *
Dongle (all models) 19R3017 *
Mouse, optical wheel (models KUA KAA KNA KJA KGA) 89P5089 *
RJ11 connector adapter (Spain, Ireland) (All ″G″ models) 60H6043 *
RJ11 connector adapter (Austria) (All ″G″ models) 60H6045 *
RJ11 connector adapter (Belgium) (All ″G″ models) 60H6046 *
RJ11 connector adapter (Denmark) (All ″G″ models) 60H6047 *
RJ11 connector adapter (Norway, Finland) (All ″G″ models) 60H6048 *
RJ11 connector adapter (France) (All ″G″ models) 60H6049 *
Chapter 9. Parts listing 233
