2
3
4
Step
Screw
(quantity)
Color
Torque
2
M2
×
12
mm,
bind-head,
nylon-coated
(1)
Black
0.245
Nm
(2.5
kgfcm)
When
installing:
Make
sure
that
the
connector
4
and
the
LCD
cable
retainer
3
are
firmly
attached,
and
then
secure
them
with
the
screw.
(continued)
Removing
and
replacing
a
FRU
96
R50e
(MT1834,
1842)
