IBM ThinkPad R50e Series

1130 PC Card slot assembly
For access, remove these FRUs in order:
v “1010 Battery pack” on page 65
v “1020 Hard disk drive” on page 66
v “1040 Keyboard” on page 69
v “1080 Keyboard bezel” on page 77
v “1120 Speaker assembly” on page 84
1
Step Screw (quantity) Color Torque
1 M2 × 4 mm, flat-head,
nylon-coated (2)
Black 0.245 Nm
(2.5
kgfcm)
(continued)
Removing and replacing a FRU
86 R50e (MT1834, 1842)
