IBM ThinkPad R50e Series

1060 DIMM (standard)
For access, remove these FRUs in order:
v “1010 Battery pack” on page 65
v “1040 Keyboard” on page 69
2
1
1
When installing: Insert the notched end of the DIMM into
the socket. Press the DIMM firmly, and
pivot it until it snaps into the place.
Make sure that it is firmly fixed in the
slot and does not move easily.
Removing and replacing a FRU
74 R50e (MT1834, 1842)
