IBM ThinkPad R50e Series

1140 Ultrabay Enhanced shield kit
For access, remove these FRUs in order:
v “1010 Battery pack” on page 65
v “1020 Hard disk drive” on page 66
v “1040 Keyboard” on page 69
v “1050 Ultrabay device” on page 73
v “1080 Keyboard bezel” on page 77
Note:
Step 1 is only for the models with 15.0-in. LCD.
For the other models, skip this step.
1
Step Screw (quantity) Color Torque
1 M2 × 12 mm, bind-head,
nylon-coated (1)
Black 0.245 Nm
(2.5
kgfcm)
(continued)
Removing and replacing a FRU
ThinkPad R50e Series 89
