IBM ThinkPad R50e Series

2010 LCD front bezel
For access, remove these FRUs in order:
v “1010 Battery pack” on page 65
v “1020 Hard disk drive” on page 66
v “1040 Keyboard” on page 69
v “1050 Ultrabay device” on page 73
v “1080 Keyboard bezel” on page 77
v “1140 Ultrabay Enhanced shield kit” on page 89
v “1150 LCD assembly” on page 95
1
1
1
Step Screw
cap
Screw (quantity) Color Torque
1 M2.5 × 4.8 mm,
bind-head, nylon-coated
(3)
Black 0.392 Nm
(4
kgfcm)
(continued)
Removing and replacing a FRU
108 R50e (MT1834, 1842)
