IBM ThinkPad R50e Series

1080 Keyboard bezel
For access, remove these FRUs in order:
v “1010 Battery pack” on page 65
v “1040 Keyboard” on page 69
2
2
1
1
1
2
2a
2
Screw 2a is only for the models with 15.0-in. LCD.
Step Screw (quantity) Color Torque
1 M2 × 3 mm, small-head,
nylon-coated (3)
Silver 0.245 Nm
(2.5
kgfcm)
2 M2 × 6 mm, bind-head,
nylon-coated (4)
Black 0.245 Nm
(2.5
kgfcm)
2a M2 × 6 mm, bind-head,
nylon-coated (1)
Black 0.245 Nm
(2.5
kgfcm)
(continued)
Removing and replacing a FRU
ThinkPad R50e Series 77
