IBM ThinkPad R50e Series

1070 Modem daughter card (MDC-2)
For access, remove these FRUs in order:
v “1010 Battery pack” on page 65
v “1040 Keyboard” on page 69
1
2
1
Step Screw (quantity) Color Torque
1 M2 × 12 mm, bind-head,
nylon-coated (2)
Black 0.245 Nm
(2.5
kgfcm)
In step 2, remove the card by pulling the tab with your
fingers in the direction of the arrow.
(continued)
Removing and replacing a FRU
ThinkPad R50e Series 75
