IBM ThinkPad R50e Series

7
5
6
Step Screw (quantity) Color Torque
5 M2 × 6 mm, bind-head,
nylon-coated (1)
Black 0.245 Nm
(2.5
kgfcm)
7 M2 × 12 mm, bind-head,
nylon-coated (1)
Black 0.245 Nm
(2.5
kgfcm)
8
When installing: Make sure that the connector 8 is
firmly attached to the system board.
Then, secure the screws from the
underside of the computer.
Removing and replacing a FRU
88 R50e (MT1834, 1842)
