IBM ThinkPad R50e Series

VGA and Ultrabay Enhanced device eject button cable is
attached to S-Video gasket a. When re-installing the
cable, attach the cable as shown in figure b.
4
4
b
a
Step Screw (quantity) Color Torque
4 Hex stud (2) Silver 0.392 Nm
(4
kgfcm)
Removing and replacing a FRU
ThinkPad R50e Series 101
