IBM ThinkPad R50e Series

Remove the hinges (b) from the LCD assembly.
9
9
9
9
10
10
b
b
Step Screw (quantity) Color Torque
9 M2 × 3 mm, small-head,
nylon-coated (4)
Silver 0.245 Nm
(2.5
kgfcm)
Turn over the LCD panel and strip off the tape 11
securing the FPC (c). Then detach the connector 12 in
the direction of the arrow.
11
12
c
(continued)
Removing and replacing a FRU
114 R50e (MT1834, 1842)
