IBM ThinkPad R50e Series

FRU P/N CRU
ID
System miscellaneous parts:
v (a) Cable, RJ11-docking connector on
system board
v (b) Antenna cable guide
v (c) EMI spring, CDC
v (d) Heatsink M9 15
v (e) DC in cable
v (f) Bracket, cable hook
v (g) Bracket, VGA connector 14
v (g) Bracket, VGA connector 15
v (h) Bracket structure 14/15
v (i) Bracket, I/O plate 14/15
v Connector bag
v Blank cap, IEEE1394 connector
v Spacer, IEEE1394 connector
v (j) Retainer, LCD cable
v Bracket M7 14
v Bracket M7 15
v Ferrite core, RH
v Ferrite core, LH
v Bracket, joint 14
v Bracket, joint 15
v Cu tape, VGA cable
v Hard disk connector retainer
Note:
Italicized letters in parentheses are
references to the exploded view on page 125.
13N5167 N
System board miscellaneous parts:
v Insulator, PC Card slot
v Insulator, louver
v Insulator, docking latch
v Insulator, docking connector
v Insulator, fan
v Insulator, Mg
v Insulator, hard disk drive
v Insulator, security chip
v Shield, AI tape (large)
v Shield, AI tape (small)
v S-video gasket
v Form on system board
v Insulator, louver, hard disk drive
v Stud, triangle
v Microphone rubber 14
v Audio connector bracket
v Security chip spacer
v Stud, system board
13R2821 N
(continued)
Parts list
138 R50e (MT1834, 1842)
