IBM Spectrum Archive
The IBM Spectrum Archive linear tape file system (previously known as LTFS) is a file system that works
with LTO Generation tape technology to access data stored on an IBM tape cartridge.
IBM Spectrum Archive uses the file system’s format and resources of the operating system (OS) on which
it is running to graphically display the contents of a tape cartridge in the OS’s graphical user interface
(GUI) format; typically a folder/tree structure. With the host operating system’s graphical File Manager,
reading data on an LTO tape cartridge is as easy as dragging and dropping. Users can run any
application that is designed for disk files against tape data without concern for the fact that the data is
physically stored on tape.
Specifications
Specifications for the tape drive. Specifications for tape cartridges are given in “Environmental and
shipping specifications for tape cartridges” on page 52.
Table 3. Specifications
Physical Specifications
Specification Dimensions
Width 213 mm (8.4 in.)
Length 332 mm (13.1 in.)
Height 58 mm (2.3 in.)
Weight 4.3 kg (9.4 lbs.)
Power Specifications
AC line voltage 100 - 240 Vac
Line frequency 50 - 60 Hz, auto-ranging
Line current at 100 Vac 0.48 A
Line current at 240 Vac 0.20 A
Other Specifications
Maximum altitude 3048 m (10,000 ft)
Maximum altitude for
shipping
12192 m (40,000 ft)
Environmental Specifications
Environmental Factor Operating Storage Shipping
Temperature 10 - 38°C (50 - 100°F) -40 to 60°C (-40 to 140°F) -40 to 60°C (-40 to 140°F)
Relative humidity 20 - 80% 10 - 90% 10 - 90%
Maximum wet bulb
temperature
26°C(79°F) Non-condensing Non-condensing
6 IBM TS2280: Setup, Operator, and Service Guide Machine Type 3580 Model H8S
