Note: If you inserted an invalid tape cartridge, error code
J
or
7
appears in the SCD. If you inserted
a write-protected cartridge, or the media has read-only compatibility, error code
P
appears in the SCD.
In either case, the tape drive unloads the cartridge and exits Maintenance mode after the cartridge is
removed.
1. Place the drive in Maintenance mode. For instructions, see “Entering Maintenance mode” on page 23.
2. Press Unload once per second until
E
displays in the SCD. (If you cycle past the wanted code, press
Unload once per second until the code reappears.)
3. Press and hold Unload for three or more seconds, then release it to select the function. The SCD
changes to a flashing
C
, requesting a cartridge.
4. Ensure that the write-protect switch on the cartridge is off, then insert the cartridge (or the tape drive
exits Maintenance mode). The SCD changes to a flashing
E
. The tape drive runs the tests.
v If no error is detected, the diagnostic test loops and begin again. To stop the loop, press Unload for
1 second and release. When the loop ends,
0
temporarily displays in the SCD, and the tape drive
exits Maintenance mode.
v If an error is detected, the Fault light flashes and the drive posts an error code to the SCD. To
determine the error, locate the code in Table 17 on page 65. To clear the error either turn the power
off and then on again, or reboot the drive by pressing and holding Unload for 10 seconds.
Function code F: Write performance test
Approximate Run Time = 7 minutes per loop
Total Number of Loops = 10
Function code
F
performs tests to ensure that the drive can read from and write to tape.
Press Unload to stop the diagnostic test and exit Maintenance mode. Pressing Unload once stops the test
at the end of the current test loop. Pressing Unload twice stops the test immediately. Wait for the drive to
rewind the tape and unload the cartridge.
Attention: For this test, insert only a scratch (blank) data cartridge or a cartridge that can be
overwritten. During the test, the drive overwrites the data on the cartridge.
Note: If you inserted an invalid tape cartridge, error code
J
or
7
appears in the SCD. If you inserted
a write-protected cartridge, or the media has read-only compatibility, error code
P
appears in the SCD.
In either case, the tape drive unloads the cartridge and exits Maintenance mode after the cartridge is
removed.
1. Place the drive in Maintenance mode. For instructions, see “Entering Maintenance mode” on page 23.
2. Press Unload once per second until
F
displays in the SCD. (If you cycle past the wanted code, press
Unload once per second until the code reappears.)
3. Press and hold Unload for three or more seconds, then release it to select the function. The SCD
changes to a flashing
C
, requesting a cartridge.
4. Insert a scratch (blank) data cartridge. The SCD changes to a flashing
F
and the tape drive runs the
tests.
30 IBM TS2280: Setup, Operator, and Service Guide Machine Type 3580 Model H8S
